Description
| Output Voltage | 24 V |
| Output Voltage Range | 24-28 V |
| Output Current | 5.0-4.5 A |
| Output Power | 120 W |
| PARD (20 MHz) | < 50 mVpp |
| Hold-up Time | > 34 ms @ 120 VAC > 65 ms @ 230 VAC |
| Phase Input | Single Phase |
| Input Voltage Range | 85-264 VAC (DC input range 88-375 VDC) |
| Input Frequency | 47-63 Hz |
| Input Current | < 1.12 A @ 120 VAC < 0.62 A @ 230 VAC |
| Efficiency at 100% Load (At 25°C ambient temperature by vertical mounting orientation.) | > 91.6 % @ 120 VAC > 92.7% @ 230 VAC |
| Max Inrush Current (Cold Start) | < 15 A @ 120 VAC < 15 A @ 230 VAC |
| Power Factor | > 0.99 @ 120 VAC > 0.91 @ 230 VAC |
| Leakage Current (264 VAC, 50 Hz) | TT/TN < 0.45 mA IT < 1.08 mA |
| Case Cover / Chassis | Aluminium |
| Dimensions (H × W × D) mm | 124 × 40 × 117 |
| Unit Weight | 0.63 kg |
| Cooling System | Convection |
| MTBF (as per Telcordia SR-332 (I/P: 115 VAC & 230 VAC, O/P: 100% load) for vertical mounting orientation.) | > 1,800,000 hrs |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 5 to 90% RH (Non-Condensing) |
| Operating Altitude | 0 to 5,000 m (0 to 16,400 ft); IEC/EN 61558: 0 to 2,500 m (0 to 8,200 ft) |
