Description
| Programming Languages | Ladder Diagram (LD), Structured Text (ST), Continuous Function Chart (CFC),Sequential Function Chart (SFC), C Language |
| Instruction Processing Speed | 25 ns |
| Program Capacity | 128k steps |
| Memory Capacity | 64k words (including 30k user-defined, 30k software configuration and 4k special registers) |
| Function Cards | The CPUs support up to 2 function cards |
| Max. Extension Modules | 32 modules (max. 16 analog modules / 4 communication modules) |
| Max. Number of Real Inputs/Outputs | 1,024 points (input & output) |
| CPU Built-in Inputs/Outputs | 8 DI / 12 DO |
| Input/Output Devices | 1,024 inputs (X0.0 ~ X63.15) 1,024 outputs (Y0.0 ~ Y63.15) |
| Bit Devices | 8,192 bits (M0 ~ M8191) 2,048 bits (S0 ~ S2047) |
| Timer | 512 (T0 ~ T511) |
| 16-bit Counter | 512 (C0 ~ C511) |
| 32-bit Counter | 256 (HC0 ~ HC255) |
| Pulse Output | Open collector: 6 axes, 200 kHz |
| High-Speed Counter | General: 4 CHs, 200 kHz |
| DO Type | PNP |
| Built-in Communication Port | USB, Ethernet, RS-485 x 2 |
| Communication Protocol | Modbus, Modbus TCP, EtherNet/IP, CANopen (requires a CANopen function card) |
| Ethernet Connection Resource | Modbus (Client / Server): 32 / 32, EtherNet/IP (CIP): 32 |
| Data Backup (Without Battery) | Program: Flash ROM, rewritable up to 100,000 times, Latched area : MRAM, no rewriting limit |
| Real-time Clock (RTC) | General Lithium button battery (CR1620) |
| Self-Diagnosis Function | CPU errors, built-in memory errors, and more |
| Rated Input Current | Power supply: 110 VAC ~ 240 VAC (±10%), CPU : 24 VDC (±10%) |
